LED strip lights are a versatile and energy-efficient solution for adding illumination to under counters and cabinets. Whether you're looking to enhance the ambiance in your kitchen, highlight architectural features, or improve task lighting, LED strip lights are an excellent choice. In this blog post, we will guide you through the steps to properly install LED strip lights under counter and under cabinet, ensuring a professional and seamless look.
Why Choose LED Strip Lights?
Before diving into the installation process, let's explore why LED strip lights are a popular choice for under counter and under cabinet lighting:
- Energy Efficiency: LED lights consume less power compared to traditional incandescent bulbs, making them an eco-friendly and cost-effective lighting solution.
- Versatility: Available in various colors and brightness levels, LED strip lights can be customized to suit any design preference.
- Ease of Installation: With their flexible and adhesive backing, LED strip lights are easy to install in tight spaces and around corners.
- Long Lifespan: LED lights have a longer lifespan, reducing the need for frequent replacements.
Step-by-Step Guide to Installing LED Strip Lights
1. Gather Your Materials
Before starting the installation, ensure you have all the necessary materials:
- LED strip lights
- Power supply (transformer)
- Dimmable driver (optional)
- LED controller (for color-changing lights)
- Measuring tape
- Scissors
- Rubbing alcohol and a cloth
- Mounting clips or adhesive tape (if not included with the LED strips)
2. Plan the Layout
Measure the area where you plan to install the LED strip lights. Determine the length of the strip needed and plan the placement of the power supply and any connectors. Mark the positions to ensure a smooth installation.
3. Prepare the Surface
Clean the underside of the counter or cabinet where the LED strips will be installed. Use rubbing alcohol and a cloth to remove any dust or grease. This step is crucial for ensuring that the adhesive backing of the LED strip adheres properly.
4. Cut the LED Strip
If necessary, cut the LED strip to the desired length. Most LED strips can be cut at designated points, usually marked with a scissor icon. Be sure to cut only at these points to avoid damaging the strip.
5. Attach the LED Strip
Peel off the adhesive backing from the LED strip and carefully press it onto the prepared surface. Start from one end and work your way to the other, pressing firmly to ensure good adhesion. If your LED strip does not have adhesive backing, use mounting clips or adhesive tape to secure it in place.
6. Connect the Power Supply
Connect the LED strip to the power supply. Ensure that the power supply is compatible with the voltage and wattage requirements of your LED strip. For longer strips or multiple sections, you may need additional connectors or a larger power supply.
7. Install the Dimmable Driver (Optional)
If you want to control the brightness of your LED strip lights, install a dimmable driver between the power supply and the LED strip. This allows you to adjust the light intensity to suit different tasks and moods.
8. Test the Lights
Before finalizing the installation, plug in the power supply and test the lights to ensure they are working correctly. Check for any dim or unlit sections and ensure all connections are secure.
9. Hide the Wires
To achieve a clean and professional look, hide the wires and power supply. Use cable clips or adhesive-backed cable organizers to secure the wires out of sight. If possible, place the power supply in a hidden location, such as inside a cabinet or behind a backsplash.
Tips for a Professional Finish
- Use Aluminum Channels: For a polished look and enhanced heat dissipation, install the LED strip lights in aluminum channels. These channels also protect the strips from dust and moisture.
- Avoid Shadows: Ensure even lighting by placing the LED strips close to the front edge of the counter or cabinet. This prevents shadows and provides better illumination.
- Choose the Right Color Temperature: Select a color temperature that complements your space. Warm white (2700K-3000K) creates a cozy ambiance, while cool white (4000K-5000K) is ideal for task lighting.
- Use a Diffuser: If you prefer a softer, diffused light, consider using a diffuser cover for the LED strips. This helps to evenly distribute the light and reduce glare.
Conclusion
Installing LED strip lights under counter and under cabinet is a straightforward process that can dramatically enhance the look and functionality of your space. By following these steps and tips, you can achieve a professional and seamless installation that provides beautiful, energy-efficient lighting for years to come.
